Aluminum Carbide Ball End Mills (2F)

Name: Aluminum Carbide Ball End Mills (2F)
Brand: Okazaki

Workpiece material (ISO)

N · Non-ferrous

2-flute solid-carbide ball end mill for machining aluminium and other non-ferrous metals, for curved-surface and 3D contour work. DLC-coated, Ø1–25 mm (14 catalogue items). Ships in a single coating option. Rated for ISO N material classes. Part of Okazaki's milling tool range.

Ask on LINE

Features & uses

Engineered for performance

Solid-Carbide Substrate, DLC Coating

DLC coating is standard — no uncoated option — across all 14 catalogue sizes.

2-Flute Ball-Nose Geometry

A fixed 2-flute full-radius ball-nose profile (corner radii 0.5 to 12.5 mm across the range) for curved-surface and 3D contour work.

Aluminium & Non-Ferrous Specialist

Rated for ISO N (non-ferrous metal) material class only — the aluminium-specific counterpart to the Carbide Ball Endmills 2F line drafted in this same batch.

Ø1–25 mm, 60–180 mm Overall Length

Diameters run Ø1–25 mm, with overall lengths from 60 to 180 mm across 14 sizes.

Workpiece material

Material applicability

N · Non-ferrous

Specifications

Sizes & part numbers

Aluminum Carbide Ball End Mills (2F) SBD2D

SBD2D 🔍 Click to zoom

Aluminum Carbide Ball End Mills (2F) specifications
ORDER NO.	FLUTES	Ø	CORNER R	FLUTE L	OAL	SHANK	COATING
SBD2D010	2	1 mm	0.5	2	60	4	DLC
SBD2D015	2	1.5 mm	0.75	3	60	4	DLC
SBD2D020	2	2 mm	1	6	70	6	DLC
SBD2D030	2	3 mm	1.5	8	70	6	DLC
SBD2D040	2	4 mm	2	8	70	6	DLC
SBD2D050	2	5 mm	2.5	12	80	6	DLC
SBD2D060	2	6 mm	3	12	80	6	DLC
SBD2D070	2	7 mm	3.5	13	90	8	DLC
SBD2D080	2	8 mm	4	14	90	8	DLC
SBD2D100	2	10 mm	5	18	100	10	DLC
SBD2D120	2	12 mm	6	22	110	12	DLC
SBD2D160	2	16 mm	8	30	140	16	DLC
SBD2D200	2	20 mm	10	38	160	20	DLC
SBD2D250	2	25 mm	12.5	55	180	25	DLC
